Canal

Respectful of a long tradition of coverage, the roof tile "canal" (bootleg) blends harmoniously into the landscape. Thanks to a sophisticated and accomplished production , the roof tile "canal" signed Tuilerie LAMBERT offers a high quality product. Its smooth surface and round edges give the roof an authentic, old-fashioned aesthetic.

The roof tile "canal" is available in 2 lengths: 40 or 48 cm

We have developed a system to obtain rounded edges on each side, removing the bright and sharp edges.

The installing of cap and pan tiles:

Conical shape, the curved tiles (caps) lock themselves by sliding.

Our canal tile by design, lays in a hat, not running.

For waterproofing, the overlap between two tiles must be between 14 and 17 cm, depending on the slope and exposure.

Traditionally installed on roof battens, the tile "canal" have evolved to adapt to the modern installation : they now have a tenon to hang onto the battens, and avoid slipping..

Some models of the roof tiles "canal" are available with concealed locking systems to ensure optimal support on the roof (Canal à crochet country tile, Fixocanal, Bifix).
These solutions create the advantage of a ligher rooftop, while ensuring investment in natural and sustainable materials (wood + clay).

Canal 0.40m

Length : 400 mm
Width big end : 179 mm
Width small end : 143 mm
Unit weight : 1,911 kg
Pallet weight : 1,204 t.
Quantity per pallet : 630
Number per m² : 17,5

Canal 0.48m

Length : 480 mm
Width big end : 176 mm
Width small end : 142 mm
Unit weight : 2,329 kg
Pallet weight : 1,525 t.
Quantity per pallet : 655
Number per m² : 15

Indicative value (+ or - 2mm)

For any specific color, there is a production constraint of 13,000 tiles minimum with delay .
